Hire rates Ex VAT & Delivery
1 day
£473.60
£473.60
£473.60 / day
Base Rate
2 days
£473.60
£473.60
£236.80 / day
Save: 50%
3 days
£473.60
£473.60
£157.87 / day
Save: 66%
4 days
£592.00
£592.00
£148.00 / day
Save: 68%
Week
£592.00
£592.00
£84.57 / day
Save: 82%
Transport Code: 6
*Exact transport costs will be calculated with depot
Large Access Transport Guideline
Up to 10 miles:
£85 Each way
11-20 miles:
£150 Each way
21-30 miles:
£170 Each way
Full Technical Specifications
| IPAF Category | IPAF 3b |
|---|---|
| Max. working height | 20.15m |
| Travel speed (raised) | 1.1km/h |
| Diesel tank | 30L |
| Lifting motor | 34VAC/13kW |
| Driving motor | 34AC/9kW |
| Charger | 48VDC/60A |
| Battery | 48V/320Ah |
| Diesel engine | FIRMAN AN192F/7.6kW |
| Overall weight | 8300kg |
| Jib movement | 135 degrees |
| Platform rotation | 180 degrees |
| Turret rotation | 360 degrees continuous |
| Max. working slope | X-5 degrees/Y-5 degrees |
| Travel speed (Stowed) | 6.0km/h |
| Basket size (length x width) | 1.83m x 0.79m |
| Max. platform height | 18.15m |
| Gradeability | 35% |
| Max. occupants | 2 |
| S.W.L | 250kg |
| Max. down probing depth | 1.90m |
| Max. up and over clearance | 8.18m |
| Turning radius (Inside/Outside) | 2.92m/4.49m |
| Wheelbase | 2.30m |
| Ground clearance | 0.31m |
| Turntable tailswing | 0.72m |
| Max. platform range | 10.53m |
| Max. Operating range (+0.6m) | 11.13m |
| Hydraulic tank | 145L |
